Yaesu FTM-400XDE

Beskrivelse

Flot og velholdt FTM-400XDE radioen har stort set kun blevet brugt til at lytte på kommer fra ikke ryger hjem 100 procent iorden se beskrivelsen her under kan afhentes i struer eller sendes mod Betaling ca 50-60 kr Yaesu FTM-400XDE Type: Amateur VHF/UHF transceiver Frequency range: Europe · · TX: 144-146 /430-440 MHz · · RX: 108-1000 MHz Tuning steps: 5 / 6.25 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 KHz Mode: TX: FM / NFM / DV (C4FM FDMA, 9.6 Kbps) · RX: AM / FM / NFM / DV (C4FM FDMA, 9.6 Kbps) Weight: Total: 1.2 Kg (2.64 lb) Other features: Large 3.5" color touch screen. APRS functions. Packet 1200/9600bd ready. · · Spectrum scope. ARTS. Built-in GPS. Micro-SD card. Twin RX. Receiver system: Double conversion superheterodyne · · 1st IF: 47.25 MHz (A-band) - 44.85 MHz (B-band) · · 2nd IF: 450 KHz Sensitivity: 140-150 MHz: 0.2 uV (12 dB SINAD) · 420-470 MHz: 0.2 uV (12 dB SINAD) Selectivity: AM/FM · · 12 KHz (-6 dB) · 35 KHz (-60 dB) Manufactured: 2015-2022 (Discontinued) Related documents: User manual (76 MB) · · Service manual (29 MB) Kilde: RigPix — https://www.rigpix.com/yaesu/ftm400xde.htm
